3000kN Flexible Magnesium Alloy Die Casting Machine for Small Precision Parts and Large Structural Components

Brand Name:	EMT
Model Number:	MG-300
MOQ:	1
Price:	Negotiable

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001,IATF 16949

Material:

Magnesium Alloy

Technology:

Thixomolding

Operational:

Safety

Production Capacity:

High

Weight:

18500kg

Mold Locking Force:

3000kN

Application:

Automotive Industry

Control System:

PLC + HMI

Power Source:

Electric

Operate:

Simple

Injection Pressure:

110/65 MPa

Power Supply:

380V/50Hz

Warranty:

1 Year

Energy Saving:

Yes

Product Description

3000kN Flexible Magnesium Alloy Die Casting Machine for Small Precision Parts and Large Structural Components.

No.	DESCRIPTION	UNIT	MG300
1	Mold Locking Force	kN	3000
2	Clamping Plate Dimension (Horizontal × Vertical)	mm	970×960
3	Screw Diameter	mm	51/66
4	Maximum Injection Speed Of Screw	m∕s	5
5	Rotation Speed Of Screw	r∕min	10-300
6	Systematic Operating Pressure	MPa	16
7	Electric Motor Power	kW	37
8	Machine’s Overall Dimension (L×W×H)	m	6.8×1.8×2.6

Full range of thixomolding equipment for magnesium alloys: covering multiple scene requirements:

The magnesium alloy thixomolding equipment independently developed by EMT has a complete tonnage matrix (300T, 650T, 800T, 1500T, 2500T, 4000T), which meets the diversified production needs from small precision parts (3C electronics, medical precision parts) to large structural parts (new energy vehicles, aerospace, industrial equipment). It can form magnesium alloy products ranging from 0.01-20kg, and provide selection services according to the customer's magnesium alloy product situation.

3000kN Flexible Magnesium Alloy Die Casting Machine for Small Precision Parts and Large Structural Components 0

Service industry:

3C Electronics: laptop casing, game console casing, mouse, keyboard, etc.

3000kN Flexible Magnesium Alloy Die Casting Machine for Small Precision Parts and Large Structural Components 1

New energy vehicles: steering wheel, seat frame, cup holder, armrest bracket, central control instrument panel, battery pack housing, etc.

3000kN Flexible Magnesium Alloy Die Casting Machine for Small Precision Parts and Large Structural Components 2

Outdoor equipment: bicycle frame, electric bicycle shell, photography equipment shell, night vision device shell, fishing wheel, etc.

3000kN Flexible Magnesium Alloy Die Casting Machine for Small Precision Parts and Large Structural Components 3

Medical field: surgical instruments, medical equipment, etc.

3000kN Flexible Magnesium Alloy Die Casting Machine for Small Precision Parts and Large Structural Components 4

Other fields: Other magnesium alloy lightweight products besides the four major fields mentioned above.
