High Performance 40000kn Semi Solid Slurry Preparation Magnesium Alloy Die Casting Machine For Medical Product Manufacturing

Brand Name:	EMT
Model Number:	MG-4000
MOQ:	1

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001，IATF16949

Injection Pressure:

100 MPa

Mold Locking Force:

40000kN

Forming Process:

Thixoforming

Warranty:

1 Year

Weight:

270000kg

Power Supply:

380V/50Hz

Energy Saving:

Yes

Dimensions:

Customer Required

Material:

Magnesium Alloy

Operation Mode:

Automatic

Control System:

PLC

Highlight:

magnesium alloy die casting machinery

magnesium alloy die casting process machine

magnesium alloy die casting production line

Product Description

High-Performance 40000kN Semi-Solid Slurry Preparation Magnesium Alloy Die Casting Machine for Medical Product Manufacturing

No.	DESCRIPTION	UNIT	MG4000
1	Mold Locking Force	kN	40000
2	Mold Lock Stroke	mm	1800
3	Screw Diameter	mm	170
4	Injection Pressure	MPa	100
5	Theoretical Injection Volume	cm³	13618
6	Systematic Operating Pressure	MPa	16
7	Ejector Force	kN	950
8	Machine’s Overall Dimension (L×W×H)	m	19×7.2×6

The principle of the semi-solid injection molding equipment for magnesium alloys:

The magnesium alloy particle raw material enters the semi-solid slurry preparation tube (material tube) by negative pressure and gravity, and is hot melted in the material tube to form a solid-liquid two-phase mixture (semi-solid slurry) under the action of screw stirring and shearing. Due to the stirring and shearing, the solid phase becomes spherical and the slurry has good fluidity. In this state, the slurry is high-speed pressed into the mold for molding, cooled and shaped, and the integrated magnesium alloy product can be obtained.

High Performance 40000kn Semi Solid Slurry Preparation Magnesium Alloy Die Casting Machine For Medical Product Manufacturing 0

Applied Industry:3C Electronic Products

High Performance 40000kn Semi Solid Slurry Preparation Magnesium Alloy Die Casting Machine For Medical Product Manufacturing 1

Applied Industry:New Energy Vehicles

High Performance 40000kn Semi Solid Slurry Preparation Magnesium Alloy Die Casting Machine For Medical Product Manufacturing 2

Applied Industry:Outdoor Products

High Performance 40000kn Semi Solid Slurry Preparation Magnesium Alloy Die Casting Machine For Medical Product Manufacturing 3

Applied Industry:Medical Products

High Performance 40000kn Semi Solid Slurry Preparation Magnesium Alloy Die Casting Machine For Medical Product Manufacturing 4
