15000kN Thixomolding Machine for Magnesium Alloy Products Complete Tonnage Matrix and Versatile Production Capabilities

Brand Name:	EMT
Model Number:	MG-1500
MOQ:	1

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001，IATF16949

Product Type:

Injection Molding Machine

Oem:

Yes

Operational:

Safety

Technology:

Thixomolding

Power Supply:

AC 380V, 50Hz

Die Height:

500-1400mm

Power Source:

Electric

Injection Pressure:

100 MPa

Casting Method:

Die Casting

Material Compatibility:

Magnesium Alloys

Mold Locking Force:

15000kN

Control System:

PLC

Operate:

Simple

Product Description

15000kN Thixomolding Machine for Magnesium Alloy Products Complete Tonnage Matrix and Versatile Production Capabilities.

No.	DESCRIPTION	UNIT	MG1500
1	Mold Locking Force	kN	15000
2	Clamping Plate Dimension (Horizontal × Vertical)	mm	2010×1960
3	Screw Diameter	mm	130
4	Maximum Injection Speed Of Screw	m∕s	5
5	Rotation Speed Of Screw	r∕min	10-285
6	Systematic Operating Pressure	MPa	16
7	Electric Motor Power	kW	2×45
8	Machine’s Overall Dimension (L×W×H)	m	14×6.4×4.5

Full range of thixomolding equipment for magnesium alloys: covering multiple scene requirements:

The magnesium alloy thixomolding equipment independently developed by EMT has a complete tonnage matrix (300T, 650T, 800T, 1500T, 2500T, 4000T), which meets the diversified production needs from small precision parts (3C electronics, medical precision parts) to large structural parts (new energy vehicles, aerospace, industrial equipment). It can form magnesium alloy products ranging from 0.01-20kg, and provide selection services according to the customer's magnesium alloy product situation.

15000kN Thixomolding Machine for Magnesium Alloy Products Complete Tonnage Matrix and Versatile Production Capabilities 0

Service industry:

3C Electronics: laptop casing, game console casing, mouse, keyboard, etc.

15000kN Thixomolding Machine for Magnesium Alloy Products Complete Tonnage Matrix and Versatile Production Capabilities 1

New energy vehicles: steering wheel, seat frame, cup holder, armrest bracket, central control instrument panel, battery pack housing, etc.

15000kN Thixomolding Machine for Magnesium Alloy Products Complete Tonnage Matrix and Versatile Production Capabilities 2

Outdoor equipment: bicycle frame, electric bicycle shell, photography equipment shell, night vision device shell, fishing wheel, etc.

15000kN Thixomolding Machine for Magnesium Alloy Products Complete Tonnage Matrix and Versatile Production Capabilities 3

Medical field: surgical instruments, medical equipment, etc.

15000kN Thixomolding Machine for Magnesium Alloy Products Complete Tonnage Matrix and Versatile Production Capabilities 4

Other fields: Other magnesium alloy lightweight products besides the four major fields mentioned above.
