8000kN Customizable Magnesium Alloy Die Casting Machine for New Energy Vehicles and Industrial Equipment

Brand Name:	EMT
Model Number:	MG-800
MOQ:	1
Price:	Negotiable

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001,IATF 16949

Control System:

PLC

Die Height:

350-1050mm

Material:

Magnesium Alloy

Operate:

Simple

Product Type:

Die Casting Machine

Production Capacity:

High

Forming Process:

Thixoforming

Operation Mode:

Automatic

Injection Stroke:

300mm

Casting Method:

Die Casting

Operational:

Safety

Locking Force:

8000kN

Oem:

Yes

Weight:

43000kg

Power Source:

Electric

Injection Pressure:

105MPa

Product Description

8000kN Customizable Magnesium Alloy Die Casting Machine for New Energy Vehicles and Industrial Equipment.

No.	DESCRIPTION	UNIT	MG800
1	Mold Locking Force	kN	8000
2	Clamping Plate Dimension (Horizontal × Vertical)	mm	1470×1480
3	Screw Diameter	mm	92
4	Maximum Injection Speed Of Screw	m∕s	5
5	Rotation Speed Of Screw	r∕min	10-300
6	Systematic Operating Pressure	MPa	16
7	Electric Motor Power	kW	55
8	Machine’s Overall Dimension (L×W×H)	m	10.5×2.3×3.3

Full range of thixomolding equipment for magnesium alloys: covering multiple scene requirements:

The magnesium alloy thixomolding equipment independently developed by EMT has a complete tonnage matrix (300T, 650T, 800T, 1500T, 2500T, 4000T), which meets the diversified production needs from small precision parts (3C electronics, medical precision parts) to large structural parts (new energy vehicles, aerospace, industrial equipment). It can form magnesium alloy products ranging from 0.01-20kg, and provide selection services according to the customer's magnesium alloy product situation.

8000kN Customizable Magnesium Alloy Die Casting Machine for New Energy Vehicles and Industrial Equipment 0

Service industry:

3C Electronics: laptop casing, game console casing, mouse, keyboard, etc.

8000kN Customizable Magnesium Alloy Die Casting Machine for New Energy Vehicles and Industrial Equipment 1

New energy vehicles: steering wheel, seat frame, cup holder, armrest bracket, central control instrument panel, battery pack housing, etc.

8000kN Customizable Magnesium Alloy Die Casting Machine for New Energy Vehicles and Industrial Equipment 2

Outdoor equipment: bicycle frame, electric bicycle shell, photography equipment shell, night vision device shell, fishing wheel, etc.

8000kN Customizable Magnesium Alloy Die Casting Machine for New Energy Vehicles and Industrial Equipment 3

Medical field: surgical instruments, medical equipment, etc.

8000kN Customizable Magnesium Alloy Die Casting Machine for New Energy Vehicles and Industrial Equipment 4

Other fields: Other magnesium alloy lightweight products besides the four major fields mentioned above.
