Thixomolding MG-650T Die Casting Machine For Magnesium Alloy Die Cast Industry Semi Solid Forming Way

Name: Thixomolding MG-650T Die Casting Machine For Magnesium Alloy Die Cast Industry Semi Solid Forming Way
Brand: Jiangsu EMT Precision Manufacturing Co., Ltd.
SKU: MG-650T
Availability: InStock

Brand Name:	EMT
Model Number:	MG-650T
MOQ:	Negotiable
Price:	Negotiable
Payment Terms:	T/T,Western Union
Supply Ability:	60000PCS /Month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

TS16949、IOS9001

Theoretical Injection Volume:

1662cm³

Theoretical Injection Mass:

2426g

Forming Process:

Thixoforming

Systematic Operating Pressure:

16MPa

Forming Way:

Semi-solid

Locking Force:

6500

Packaging Details:

According to customer needs

Supply Ability:

60000PCS /Month

Highlight:

Magnesium Alloy Die Cast Industry machine

Thixomolding Die Casting Machine

Product Description

Thixomolding Magnesium Alloy Die Casting Machine,MG-650T,Semi-Solid forming way.

No.	DESCRIPTION	UNIT	MG-650T
I. Mold locking
1	Mold Locking Force	kN	6500
2	Mold Lock Stroke	mm	720
3	Mold Thickness (Minimum To Maximum)	mm	350-900
4	Clamping Plate Dimension (Horizontal × Vertical)	mm	1300×1300
5	Column Spacing (Horizontal × Vertical)	mm	810×810
6	Way Of Mold Installation	-	T-groove way
II. Others
1	Systematic Operating Pressure	MPa	16
2	Ejector Force	kN	250
3	Ejector Stroke	mm	150
4	Electric Motor Power	kW	45
5	Heater’s Output Power	kW	50
6	Melting Servo Motor Power	kW	42
7	Total Electric Capacity	kW	140
8	Oil Tank Capacity	L	1000
9	Machine Weight	kg	35500
10	Machine’s Overall Dimension (L×W×H)	m	9.5×2.3×3.3

Significantly reducing the purchase and usage costs of thixomolding equipment for magnesium alloys and the manufacturing costs of magnesium alloy parts, breaking through the biggest bottleneck of the widespread application of magnesium alloys.

Thixomolding MG-650T Die Casting Machine For Magnesium Alloy Die Cast Industry Semi Solid Forming Way 0

Packing and Shipping:

1. The machines are usually transported by bare machines. The key parts (such as electric boxes, electrical components, hydraulic components, etc.) shall be packed with pearl cotton and plastic films. The mechanical parts shall be coated with butter, which is moisture-proof and rust proof to be suitable for long-distance transportation.

2. The Seller shall consign the goods according to the buyer's request.

Thixomolding MG-650T Die Casting Machine For Magnesium Alloy Die Cast Industry Semi Solid Forming Way 1

Thixomolding MG-650T Die Casting Machine For Magnesium Alloy Die Cast Industry Semi Solid Forming Way 2

Thixomolding MG-650T Die Casting Machine For Magnesium Alloy Die Cast Industry Semi Solid Forming Way 3

Advantage:
