EMT Thixomolding Machine 800T Magnesium Alloy Injection Molding Machine
Mg-800 magnesium alloy semi-solid injection molding machine
Technical parameters
| No. | Description | Unit | MG-800 |
| I. Mold locking | |||
| 1 | Mold locking force | kN | 8000 |
| 2 | Mold lock stroke | mm | 800 |
| 3 | Mold thickness (minimum to maximum) | mm | 380-1000 |
| 4 | Clamping plate dimension (horizontal × vertical) | mm | 1470x1480 |
| 5 | Column spacing (horizontal × vertical) | mm | 940×940 |
| 6 | Way of mold installation | T-groove way | |
| II. Injection | |||
| 1 | Screw diameter | mm | 92 |
| 2 | Injection pressure | MPa | 105 |
| 3 | Theoretical injection volume | cm³ | 1994 |
| 4 | Theoretical injection mass | g | 2911 |
| 5 | Theoretical injection rate | cm³∕s | 30578 |
| 6 | Screw’s maximum injection speed | m∕s | 5 |
| 7 | Screw’s rotation speed | r∕min | 10-300 |
| 8 | Injection stroke | mm | 300 |
| 9 | Injection nozzle dimension | mm | φ20×R35 |
| 10 | Injection nozzle inlet | mm | 75 |
| 11 | Injection nozzle contact force | kN | 480 |
| 12 | Injection device position | mm | 0,-175 |
| I. Others | |||
| 1 | Systematic operating pressure | MPa | 16 |
| 2 | Ejection force | kN | 250 |
| 3 | Ejection stroke | mm | 150 |
| 4 | Electric motor power | kW | 55 |
| 5 | Heater’s output power | kW | 50 |
| 6 | Melting servo motor power | kW | 42 |
| 7 | Total electric capacity | kW | 150 |
| 8 | Oil tank capacity | L | 1000 |
| 9 | Machine weight | kg | 43000 |
| 10 | Machine’s overall dimension (L×W×H) | m | 10.5x2.3x3.3 |
Product Description:
①. Before-sale service
1. Investment budget: to provide product analysis. Budget of casting equipment and its auxiliary devices. Human resource allocation budget service.
2. Plant planning: to provide equipment arrangement, workshop ventilation, gas exhaust, water transportation, wiring, hoisting equipment design service. 3. Equipment overhaul: providing various casting dedicated equipment overhaul service.
②. In-sale service
1. Peripheral information: to provide injection molding machine peripheral equipment suppliers, such as water towers, furnaces, molds, polishing devices, air compressors, etc
2. Machine foundation: to provide machine foundation drawings, and to assist customers in making foundation.
3. Production assistance: to assist customers in preparing for injection molding production.
4. Machine installation: When the machine arrives at the customer's factory, the professional and technical personnel will pick up the machines and guide customers to install water, electricity, gas and machines.
5. Personnel support: to recommend casting professionals for customers.
6. Training support: to provide customers with training service.
③. After-sale service
1. It will be available within 48 hours after receipt of a customer’s repair report telephone. (It will depend on the traffic situation if it is a remote area).
2. Trial service: Customers will be provided with trial service, and customers’ personnel will receive on-the-site training.
3. Machine maintenance: warranty and free materials within one year (except hot work pieces, quick-wear parts and man-made damage), and lifelong repair.
4. Regular visit: regular visit to customers, to guide customers to use and maintain the machines.
5. Technical support: dedicated mold and process engineers to assist customer in solving difficulty and problems in the production process to improve customers’ product quality.
6. Maintenance support: to recommend professional repair personnel for large customers to ensure timely repair and reduce repair cost.
④. Charging standards for after-sale service
1. No cost of components will be charged within the warranty period (except man-made factors) and service fees.
2. Cost of components and appropriate service fees will be charged beyond the warranty period (1 year).
Advantage:
FAQ:
1. Q:Are you a factory or a trading company?
A:We are a factory which has been focus on Magnesium alloy deep processing lightweight field & semi-solid injection molding of Magnesium alloy for more than 16+ years.
2. Q: Is there quality control on all production lines?
A: Yes, all production lines have adequate quality control.
3. Q: Has the company established and implemented a standard procedure for purchasing contract review and approval?
A: Yes, with written standard procedures.
4. Q: Is there a procedure to conduct random product inspections after final packaging?
A: Yes, with clear standard and written inspection records.
5. Q: How can I get a quotation?
A: Please kindly send us following information 1) Product drawings by STEP/STP/PRT/PDF/IGS format etc. 2) Material, size and surface treatment request. 3) Required quantity. Normally,the quote will be offer in 1-6 hours. :)
6. Q: What is your payment terms?
A: T/T, Western Union, etc.
Our products are sold all over the world, you can rest assured.
